Volume-DaoPham92-PY// 1. Buy / Sell Volume
// 2. Delta Flow
// 3. Volume Spike / Exhaustion
// 4. POC / VWAP Context
// 5. HTF BOS / CHOCH / MSS
// 6. RSI + RSI EMA
// 7. News / Session Risk
Pine Script® 인디케이터
볼륨 인디케이터
Forum Initium + LTA Session Breaks LTA Forum Initium + Session Breaks is a confluence indicator built to map key weekly and session-based reference levels on intraday charts.
It combines:
• Forum Initium, defined here as the opening price of the new weekly candle
• Previous Week High and Previous Week Low
• Daily session break markers
• New York 18:00 timing marker
• A live weekly bias table based on price relative to Forum Initium
• A configurable approach zone around Forum Initium for reaction monitoring
How it works:
• At the start of each new trading week, the script stores the new weekly open as Forum Initium.
• Previous week high/low are requested from the weekly timeframe using non-repainting higher-timeframe logic.
• Daily session changes are marked with vertical dotted separators.
• A separate vertical marker is drawn when the chart bar time aligns with 18:00 in the New York timezone.
• A bias table displays whether price is trading above or below Forum Initium.
• A background highlight appears when price moves within a configurable distance of Forum Initium.
This script is designed for traders who use weekly reference levels and session timing as context rather than as standalone signals. It is most useful on lower intraday timeframes such as 1-minute and 5-minute charts across Gold, Forex, indices, and crypto.
Notes:
• This is a confluence tool, not an entry model.
• The script is designed to avoid repainting by using confirmed weekly state changes and request.security() with lookahead_off .
• Session markers and weekly levels are intended to provide structure for discretionary execution.
Pine Script® 인디케이터
Volume ConvictionVolume Conviction — Candle Classification by Volume & Body
This indicator classifies every candle into one of four states based on the relationship between candle body size and relative volume, giving you an instant read on the strength or weakness behind each price move.
The core idea is simple: a big-bodied candle with high volume indicates genuine conviction — participants are aggressive and the move is likely to continue. A small-bodied candle with high volume indicates absorption — large players are on the other side soaking up the move, warning of a potential reversal or stall. Low volume moves are faded visually to signal a lack of participation and fade risk.
Four candle states:
🟢 Conviction bull — large body + high volume. Bright green candle + triangle below. Move likely continues up.
🔴 Conviction bear — large body + high volume. Bright red candle + triangle above. Move likely continues down.
🟡 Absorption — small body + high volume. Yellow candle + circle above. Both sides fighting — watch for reversal on the next bar.
⬜ Weak move — large body but low volume. Heavily faded candle, no marker. Move is unsupported, high fade risk.
How to use it:
Watch for sequences rather than individual candles. A string of conviction candles followed by an absorption candle is a classic exhaustion pattern — the move is running out of willing participants. Pair absorption signals near key levels such as a point of control, session high/low, or major support and resistance for the highest probability reversal setups.
Inputs you can tune:
Volume average length (default 20 bars)
Body ratio thresholds for conviction and absorption
High and low volume multipliers
Optional text labels on signal bars
Built for 1-minute scalping but works on any timeframe. Designed for crypto but applicable to any liquid market.
Pine Script® 인디케이터
Enhanced VolumeEnhanced Volume (EV)
A comprehensive volume analysis tool designed to give traders a complete picture of buying and selling activity at a glance.
Key Features:
Relative Volume Colour Coding
Bars are automatically colour-coded based on volume significance — high relative volume bars stand out immediately, while low relative volume bars are flagged to help you avoid low-conviction moves.
Smart Labels
Automatically labels notable volume events directly on the chart:
High relative volume bars (2× average and above)
Highest volume in the past year (HV1Y)
Highest volume ever recorded for the instrument (★ HVE)
All labels display the raw volume figure and the percentage above average so you can assess conviction instantly.
Projected Volume
During the trading session, a projected end-of-day volume bar is calculated based on the current rate of flow. A projected run-rate percentage tells you whether today is on track to be a high or low volume day before the session closes.
2× and 3× Average Lines
Visual reference lines show exactly where 2× and 3× average volume sit, making it easy to gauge how significant the current bar really is.
Up/Down Volume Ratio
Tracks cumulative buying versus selling volume over a configurable lookback period, giving you a directional bias reading based on actual volume flow rather than price alone.
Summary Table
A clean on-chart table displays all key metrics in one place — current volume, average volume, average dollar volume, up/down ratio, relative volume percentage, projected volume, and volume ratio.
Inputs:
SMA length for average volume calculation
High and low relative volume thresholds
1-year lookback period for HV1Y detection
Up/Down volume lookback period
Toggle projected volume bar and 2×/3× lines on or off
Full colour customisation for all bar states
Built for momentum and breakout traders who use volume as a primary confirmation tool.
Pine Script® 인디케이터
Profilo Volume + Sessioni versione 1.2Profilo Volume + Range Sessioni, lavora su base fuso orario Europa/Roma
Ho inserito tooltip in modo tale da poter impostare bene lo script sulla base dei vostri parametri ideali
Aggiornerò continuamente lo script, quindi cercate di aggiornarlo se tradingview vi da avviso di aggiornamento disponibile
per qualsiasi richiesta, bug o miglioramenti scrivete pure nei commenti
spero che possa esservi di grande aiuto
Pine Script® 인디케이터
AVDO + Proporcion de volumen SR by TraderDeConfianzaEste es un indicador todo-en-uno que combina dos sistemas complementarios para detectar zonas de interés institucional y dirección de tendencia. Es una herramienta de análisis basada en lectura de volumen real, por lo que su efectividad depende directamente de la calidad y autenticidad de los datos de volumen del activo que analizas.
Importante: dónde funciona y dónde no
El motor principal del indicador es el volumen real (transacciones efectivamente ejecutadas en un exchange centralizado). Por eso, su rendimiento varía dramáticamente según el tipo de activo:
Activos recomendados (volumen real y confiable):
Futuros de CME Group: especialmente los futuros de índices americanos como MNQ, NQ, ES, MES, YM, MYM, RTY, M2K. También funciona bien en futuros de commodities (CL, GC, SI, NG) y de bonos (ZN, ZB, ZF). El volumen de CME es centralizado y refleja transacciones reales.
Criptomonedas (preferentemente Binance): BTC, ETH, SOL y altcoins principales. Binance concentra el mayor volumen real del mercado cripto spot y de perpetuos. Otros exchanges grandes como Bybit, OKX o Coinbase también funcionan bien. Evita exchanges menores con volumen inflado.
Acciones directas (NYSE, NASDAQ, ARCA, AMEX): AAPL, TSLA, NVDA, SPY, QQQ y cualquier acción de alta liquidez listada en exchanges americanos primarios. El volumen es transparente y auditable.
No recomendado:
CFDs (Contracts for Difference): el volumen mostrado en CFDs es sintético, derivado del proveedor del broker, y no representa transacciones reales del mercado subyacente. El indicador perderá fiabilidad porque sus señales se basarán en datos artificiales.
Forex spot retail: el mercado forex no es centralizado, no existe un volumen "real" verificable. Lo que se muestra como volumen suele ser tick count del broker, no contratos negociados.
Mercados ilíquidos o de bajo volumen: acciones penny, criptos con poca capitalización, instrumentos exóticos. El ruido en los datos hace que las señales no sean confiables.
¿Qué hace el indicador?
Combina dos motores independientes que trabajan en armonía:
Motor 1 — AVDO (Anchored Value Distribution Oscillator): un sistema avanzado de distribución de valor anclada. Construye un perfil de volumen dinámico, identifica las zonas de valor (donde se ha negociado la mayor parte del volumen) y deriva una línea de tendencia adaptativa (trailing) que se mueve con el precio. Además, colorea las velas según el "estado" del mercado: alcista, bajista o neutral. Cuando detecta velas con volumen crítico histórico, las pinta de amarillo como advertencia de actividad institucional excepcional.
Motor 2 — VolProp SR (Volumen Proporcional Soporte/Resistencia): detecta velas donde el volumen actual supera al de la vela anterior en una proporción configurable. Marca esa vela con una caja que cubre todo su rango (high-low) y la proyecta hacia la derecha como zona activa de soporte o resistencia. La caja se mantiene viva hasta que el precio cierre atravesándola — momento en que se considera "mitigada" y se vuelve gris.
Cuando ambos motores se alinean, tienes confluencia institucional: precisamente las zonas donde los grandes operadores están dejando huella.
Filosofía de configuración
La mayoría del indicador viene listo para usar tal como está. Los componentes de AVDO y Volumen Crítico están afinados con parámetros robustos que funcionan bien en la mayoría de activos sin necesidad de ajuste. Déjalos en sus valores por defecto a menos que tengas una razón muy específica para tocarlos.
El verdadero trabajo de calibración está en el Motor 2 (VolProp SR), específicamente en dos parámetros: la proporción de volumen y el multiplicador ATR. Estos dos son los que adaptas a cada activo y timeframe que operes. El objetivo es encontrar el balance donde el indicador te marca solo las zonas verdaderamente institucionales, sin saturar el gráfico con ruido ni dejar pasar señales válidas.
Cómo calibrar VolProp para cada activo
Proceso recomendado:
Carga el indicador en el activo y timeframe que vas a operar. Déjalo en valores default (proporción 1.5, ATR multiplicador 1.0).
Observa 30 a 50 señales históricas sin tocar nada. Anota cuántas cajas aparecen por sesión y cuántas funcionaron realmente como S/R cuando el precio regresó a tocarlas.
Si aparecen demasiadas cajas y muchas no funcionan (gráfico saturado, señales ruidosas):
Sube la proporción de volumen en pasos de 0.2 (de 1.5 → 1.7 → 2.0).
Sube el multiplicador ATR en pasos de 0.2 (de 1.0 → 1.2 → 1.5).
Repite la observación.
Si aparecen muy pocas cajas (gráfico vacío, te pierdes movimientos importantes):
Baja la proporción de volumen en pasos de 0.1 (de 1.5 → 1.4 → 1.3).
Baja el multiplicador ATR (de 1.0 → 0.8).
O desactiva temporalmente el filtro ATR para diagnosticar dónde se está bloqueando.
Repite hasta que cada sesión te entregue entre 3 y 8 cajas activas de calidad — suficientes para tener oportunidades, no tantas que ensucien el análisis.
Y ajusta también según timeframe: timeframes bajos (1m–5m) toleran proporciones más bajas, timeframes altos (1H+) requieren proporciones más altas para que la señal sea significativa.
Parámetros del indicador
Grupo AVDO • Core (déjalo como está)
Lookback (default 233): número de barras usadas para construir la distribución de volumen. Solo bájalo si quieres reactividad extrema en scalping, o súbelo para contextos macro.
Canvas Pad (default 0.03) y Rebuild Drift (default 0.2): afinan internamente cómo se construye el perfil. No los toques sin razón específica.
Grupo AVDO • Signal (déjalo como está)
Signal Line Length (default 50): línea de señal interna del oscilador. Bájalo solo si quieres cruces más rápidos para scalping agresivo.
Grupo AVDO • Trend Logic (déjalo como está)
Show Trail on Chart, Fill, Profile Center Bias, Trail Acceleration, Max Trail Acceleration: todos vienen optimizados. Solo modifica si entiendes el efecto exacto que buscas — por ejemplo, subir Trail Acceleration si quieres un trailing más agresivo en mercados de alta volatilidad.
Grupo AVDO • Display
Show Reversal Marks (default OFF): actívalo si quieres diamantes de reversión visuales. Útil para alertas tempranas de techo/piso.
Trend Candlesticks (default ON): si lo desactivas, las velas se ven con su color real verde/rojo nativo. Recomendado dejar ON.
Grupo AVDO • Colors (estética)
Personaliza los colores a tu gusto. El amarillo del Volumen Crítico tiene prioridad sobre los demás, así que recuerda que ese color destaca lo más relevante.
Grupo AVDO • Volumen Crítico (déjalo como está)
Lookback Volumen (89), Suavizado Volumen (21), Umbral Crítico (0.618 — ratio áureo): los defaults están finamente calibrados con principios de teoría de mercado clásica. Solo súbelos si tu activo es muy ruidoso y aparecen demasiadas velas amarillas, o bájalos si casi nunca aparecen.
Grupo VolProp • Detección (★ AJUSTE PRINCIPAL)
Proporción de volumen (default 1.5): el parámetro más importante del indicador. Define cuánto debe crecer el volumen de la vela actual respecto a la anterior para disparar una caja.
Este es uno de los dos parámetros que debes calibrar para cada activo. Sigue el proceso descrito arriba.
Grupo VolProp • Filtro ATR (★ AJUSTE PRINCIPAL)
Activar filtro ATR (default ON): mantenlo activado, descarta velas pequeñas que tuvieron volumen alto pero no movieron precio.
Período ATR (default 14): estándar técnico, no necesita ajuste.
Multiplicador ATR (default 1.0): el segundo parámetro a calibrar por activo. Define qué tan grande debe ser la vela respecto a la volatilidad promedio reciente. Ajústalo según el proceso de calibración descrito.
Grupo VolProp • Filtro Cuerpo
Activar filtro cuerpo dominante (default ON): descarta dojis y velas indecisas. Mantenlo ON.
% mínimo del cuerpo (default 60%): ajusta solo si notas que se cuelan velas con mucha mecha y cuerpo chico. Súbelo a 70-75% para mayor exigencia.
Grupo VolProp • Cajas S/R
Modo extensión (default Dinámica): déjalo en Dinámica para que las cajas se proyecten hasta que el precio las rompa. Cambia a "Fija" solo si quieres que duren un número específico de barras.
Mostrar cajas mitigadas (default ON): las cajas rotas quedan en gris como contexto histórico. Desactívalo si quieres el gráfico más limpio sin contexto previo.
Colores y ancho de borde: estética pura.
Grupo VolProp • Etiqueta
Mostrar etiqueta con ratio (default ON): muestra el "2.3x" debajo de la vela marcada para que veas qué tan fuerte fue la señal.
Tamaño y color de texto: ajustes visuales.
Ejemplo de uso paso a paso
Imagina que abres el chart de MNQ a las 8:30 AM CST (apertura de NYSE). El indicador ya está calibrado para este activo (proporción 1.8, ATR multiplicador 1.1 después de tu proceso de prueba).
Paso 1 — Lectura del contexto general (AVDO):
A las 8:30 ves que las velas vienen pintadas de verde intenso y el trailing line está claramente por debajo del precio. AVDO confirma tendencia alcista, el precio está aceptado en la zona alta del perfil de valor. No operas en contra de esto. Tu sesgo es alcista.
Paso 2 — Aparece una caja VolProp:
A las 9:15 AM, una vela explota de volumen y cumple los filtros. Aparece una caja verde semitransparente cubriendo todo su rango con etiqueta "2.4x" abajo. Significa que esa vela tuvo 2.4 veces el volumen de la anterior y pasó los filtros. Esta es tu zona de entrada potencial.
Paso 3 — Confluencia élite:
A las 9:45 AM, otra vela alcista. Esta vez la vela aparece pintada en amarillo (Volumen Crítico AVDO) y se le dibuja una caja verde de VolProp con etiqueta "3.1x". Setup A+: confluencia triple — volumen crítico histórico, ratio proporcional, y tendencia AVDO alineada.
Paso 4 — Espera el pullback:
No entras al breakout. Esperas a que el precio se aleje y regrese a tocar la caja. A las 10:20 AM, el precio retrocede y entra dentro de la caja amarilla. Esta es la señal de entrada.
Paso 5 — Entrada, stop y target:
Long con stop justo por debajo del low de la caja (extremo inferior, no el cuerpo). Target en el siguiente nivel claro: otra caja superior, una zona AVDO de resistencia, o un múltiplo de R según tu plan.
Paso 6 — Gestión:
Si el precio sigue subiendo: ¿aparece otra caja verde más arriba? → toma parcial o trail. ¿La trail de AVDO se voltea a bajista? → cierre. ¿Una caja gris previa ahora actúa como resistencia? → cuida la posición.
Reglas de oro
El AVDO da contexto, VolProp SR da zonas. No operes una caja contra el contexto. Caja verde con AVDO bajista → mejor pásala.
Vela amarilla + caja del mismo color = setup A+. Estas son las raras y valiosas. Espéralas con paciencia.
La caja gris no es zona activa. Es referencia histórica. Si el precio regresa a una caja gris y reacciona, considera el principio de polaridad (soporte roto = posible resistencia).
Operación de retorno, no de breakout. El indicador marca dónde estuvieron los institucionales. Operas el pullback a la zona, no el breakout inicial.
Calibración por activo. Lo que funciona en MNQ no funciona idéntico en BTC, ni en NVDA, ni en cada timeframe. Dedica tiempo al proceso de ajuste de proporción y ATR antes de operar en vivo.
Activa las alertas de confluencia. En la lista de alertas hay tres claves: "VolProp + Volumen Crítico", "VolProp + AVDO Bull Stack" y "VolProp + AVDO Bear Stack". Activa esas como push — son las que realmente vale la pena mirar.
Cuándo NO operarlo
Aperturas con gap brutal (primeros 5–10 minutos en días de noticia macro): el indicador necesita unas pocas velas para estabilizar el perfil.
Activos con volumen sintético o no confiable (CFDs, forex retail, mercados ilíquidos).
Cuando el contexto AVDO es plano (trailing cerca del precio, oscilador cerca de cero): el mercado está en consolidación, las cajas son menos confiables.
Sin calibración previa al activo: si lo cargas en un instrumento nuevo y operas con defaults sin observar primero, vas a ciegas.
Resumen ejecutivo
Tienes un sistema que mapea las zonas donde los institucionales dejaron huella (cajas verdes/rojas), te dice cuándo esas zonas son especialmente significativas (vela amarilla), te da la dirección de la corriente principal (trailing AVDO), y te avisa cuando todo se alinea (alertas de confluencia).
La estructura del indicador está prácticamente lista de fábrica — la parte de AVDO y Volumen Crítico viene optimizada. Tu trabajo de calibración se concentra en dos parámetros del Motor 2 (VolProp): proporción de volumen y multiplicador ATR. Ajústalos para cada activo hasta que las cajas sean significativas y proporcionadas a la sesión, y el indicador se vuelve una extensión natural de tu análisis.
Recuerda siempre: este indicador es tan bueno como el volumen real del activo que analizas. Úsalo en mercados centralizados con datos auténticos, y rendirá. Evita los mercados con volumen sintético, ahí no tiene cómo brillar.
Pine Script® 인디케이터
Exhaustion Fuel Gauge [AGPro Series]Exhaustion Fuel Gauge
🧠 Core Idea
Is the current move still powered by real participation, or is the trend running on exhausted fuel?
📌 Overview / What it does
Exhaustion Fuel Gauge is a premium TradingView overlay that evaluates trend fuel, participation strength, extension pressure, wick reaction, and momentum efficiency to map whether a directional move is still active, fading, or entering exhaustion territory.
The script produces a forward-projected fuel zone, compact state labels, current context tags, and an AGPro-style panel that summarizes the active gauge state. It is designed to help users read whether a move has enough internal fuel to continue or whether the chart is showing signs of weakening participation and exhaustion risk.
It does not predict price direction, automate trades, or provide guaranteed signals. It is a visual decision-support map for market context.
🎯 Purpose & Design Philosophy
This script was built to fill the gap between simple momentum indicators and real chart context. Many tools show whether price is moving fast, but they do not clearly explain whether the move still has fuel or whether the movement is becoming fragile.
Exhaustion Fuel Gauge helps discretionary traders, swing traders, intraday traders, and market-structure readers evaluate the quality of a move before overreacting to a single candle.
The design philosophy is simple: trend continuation should be judged by fuel, participation, efficiency, and reaction quality together.
⚡ Why This Script Is Different
Most tools focus on overbought or oversold readings.
This script does NOT treat exhaustion as a single oscillator value or a generic reversal signal.
Instead, it combines directional persistence, participation strength, range behavior, move efficiency, wick pressure, and extension risk into a clean overlay that explains whether the current move still has usable fuel.
⚙️ Methodology
1. Context Detection
The script identifies the active directional context using recent price movement and trend baseline behavior.
2. Fuel Evaluation
It measures persistence, participation, range expansion, and efficiency to estimate how much usable fuel remains in the move.
3. Exhaustion Risk Mapping
It evaluates extension, fuel fade, wick pressure, and participation fade to estimate whether the move is becoming vulnerable.
4. Visual Output
The script displays a forward-projected fuel zone, event labels, right-side context tags, and a structured AGPro panel.
🗺️ How to Read the Chart
Zones represent the current fuel reference area where the active move should be evaluated.
Labels mark important changes such as fuel activation, fuel fading, exhaustion watch, exhaustion hit, or reset build.
Colors represent state context:
• Green = active fuel
• Pink = exhaustion risk or exhaustion hit
• Yellow = caution / watch state
• Indigo = fading or reset context
The panel summarizes the current gauge state, direction, fuel score, exhaustion risk, participation, extension, and next context.
🚦 Signals & States
• FUEL ACTIVE → directional move still has usable internal fuel
• FUEL FADING → move is still present, but internal support is weakening
• EXHAUSTION WATCH → extension and reaction pressure are elevated
• EXHAUSTION HIT → exhaustion evidence is strong and fuel has weakened
• RESET BUILD → no clean directional fuel is currently confirmed
🔔 Alerts Logic
Alerts trigger when the script detects a new fuel-active state, fuel-fading state, exhaustion-watch state, exhaustion-hit state, or reset-build state.
Alerts are attention markers only. They are not trade instructions and should not be interpreted as guaranteed outcomes.
🧩 Confluence Logic
The strongest exhaustion context appears when extension pressure, participation fade, wick reaction, and weak fuel score align.
The strongest continuation context appears when fuel score remains high while exhaustion risk stays contained.
📊 When to Use
• Trending markets where continuation quality matters
• Extended moves where exhaustion risk needs to be evaluated
• Breakout follow-through analysis
• Swing-trading context review
• Intraday movement quality checks
⚠️ When NOT to Use
• Extremely low-liquidity markets
• Randomly choppy symbols with poor structure
• News spikes where normal participation behavior is distorted
• Very low timeframes with excessive noise
🎛️ Key Inputs
• Trend Length → adjusts the baseline used to define directional context
• Fuel Lookback → controls how many bars are used for fuel evaluation
• Exhaustion Threshold → adjusts how strict exhaustion detection is
• Fuel Fade Threshold → defines when a move is considered fuel-fading
• Zone Projection Bars → keeps the active zone visible for publication screenshots
• Panel and label settings → control visual readability
🖥️ Interface & Visual Design
The interface is built for quick visual interpretation.
The panel provides structured context without dominating the chart. The fuel zone gives the main story visually, while compact labels and right-side tags provide the current state without clutter.
The goal is a premium, publication-ready TradingView chart.
🧪 Practical Usage Workflow
1. Read the panel state.
2. Check whether fuel is active, fading, or exhausted.
3. Observe the active fuel zone and current right-side tags.
4. Compare exhaustion risk with participation and extension.
5. Use broader market structure before making any decision.
🔍 Interpretation Guidelines
High fuel with low exhaustion risk suggests the move still has internal support.
High exhaustion risk with weak fuel suggests the move may be vulnerable to reaction or reset.
Fuel fading does not mean reversal. It means continuation quality is weakening.
Exhaustion hit does not guarantee a top or bottom. It marks a context that deserves caution.
🚫 What This Script Is NOT
This script is not a prediction engine.
It is not financial advice.
It is not an automated trading system.
It does not provide guaranteed buy or sell signals.
It does not replace risk management or independent analysis.
⚠️ Limitations & Transparency
The script is rule-based and depends on market conditions.
Different timeframes may produce different readings.
Volatility, liquidity, gaps, and news-driven moves may affect signal quality.
Outputs should always be interpreted with broader market context.
🧠 Market Context Notes
Exhaustion is not only about price distance.
It also depends on whether participation remains strong, whether candles still close efficiently, and whether wick pressure begins to appear against the current direction.
This script is designed to make those conditions easier to read visually.
🧾 Use Case Examples
When price extends strongly but fuel remains high and exhaustion risk is contained, the move may still have continuation quality.
When price extends while participation fades and wick pressure increases, the chart may be entering exhaustion-watch territory.
When exhaustion risk rises while fuel drops, the context becomes more fragile.
🧱 System Philosophy
AGPro Series tools are designed as professional visual maps, not signal machines.
The goal is to make complex market context easier to interpret without reducing it to a simplistic buy or sell label.
🔐 Non-Promise Statement
No script can guarantee future price movement.
This tool provides structured context, not certainty.
📉 Risk Disclosure
Trading involves risk.
Past behavior does not guarantee future results.
Users are responsible for their own decisions, position sizing, and risk management.
This script does not provide financial advice.
📚 Educational Note
Use this script as a learning and analysis tool to better understand momentum quality, trend fuel, and exhaustion behavior across different market conditions.
Pine Script® 인디케이터
Candle Intent Map [AGPro Series]Candle Intent Map
🧠 Core Idea
Does this candle show initiative, absorption, rejection, indecision, or a real shift in intent?
📌 Overview / What it does
Candle Intent Map is a candle behavior and market reaction tool designed to read the internal message of price candles beyond simple bullish or bearish color.
The script evaluates body pressure, wick reaction, close location, volume context, short follow-through, and recent intent changes to classify whether the market is showing initiative, absorption, rejection, indecision, or an intent shift.
It produces compact labels, a visible intent pressure zone, right-side context tags, and a clean AG Pro panel. It does not predict price, automate decisions, or promise that a candle pattern will continue.
🎯 Purpose & Design Philosophy
This script was built because many candlestick tools stop at basic pattern recognition.
A candle is not only a shape. It is a relationship between body commitment, wick reaction, volume participation, close location, and what happens immediately after that candle forms.
Candle Intent Map helps traders who want to read candle quality, initiative pressure, reaction zones, and follow-through context without turning the chart into a crowded pattern scanner.
⚡ Why This Script Is Different
Most candle tools focus on named formations such as engulfing candles, pin bars, doji candles, or simple color changes.
This script does NOT treat every candle pattern as an automatic signal.
Instead, it studies whether the candle has enough internal pressure, reaction quality, volume context, and follow-through to deserve attention.
The goal is not to label more candles. The goal is to label the candles that tell a clearer market story.
⚙️ Methodology
1. Context Detection
The script measures body-to-range ratio, upper wick pressure, lower wick pressure, close location, and relative volume participation.
2. Intent Classification
Candles are classified into initiative, absorption, rejection, indecision, or intent shift conditions based on body pressure, wick behavior, and directional commitment.
3. Reaction Evaluation
The script builds a reaction-quality score using body strength, wick reaction, close placement, volume context, and short follow-through behavior.
4. Visual Output
The strongest current candle intent context is mapped as a visible intent zone, compact event labels, right-side state tags, and a structured AG Pro panel.
🗺️ How to Read the Chart
Zones represent the most recent candle intent pressure area.
Labels show important candle intent events such as bullish intent, bearish intent, absorption, rejection, indecision, or intent shift.
Colors separate constructive pressure, defensive pressure, neutral reaction, and absorption-style behavior.
The panel summarizes current intent, direction, body pressure, wick reaction, follow-through, quality score, and next context.
🚦 Signals & States
• BULL INTENT → bullish body pressure with meaningful close location and participation
• BEAR INTENT → bearish body pressure with meaningful close location and participation
• ABSORPTION → strong reaction behavior with compressed body and meaningful volume
• LOWER REJECT → lower wick reaction suggesting downside rejection
• UPPER REJECT → upper wick reaction suggesting upside rejection
• INDECISION → low body commitment with balanced wick behavior
• INTENT SHIFT → recent candle intent changes direction with enough pressure to matter
🔔 Alerts Logic
Alerts trigger when the script detects bullish candle intent, bearish candle intent, candle absorption, or candle intent shift.
These alerts are attention markers only. They highlight a candle context that may deserve review, not a trade instruction.
🧩 Confluence Logic
The strongest context appears when candle body pressure, wick reaction, close location, volume participation, and follow-through point in the same direction.
When these components align, the candle intent quality score becomes stronger.
📊 When to Use
• During active trend continuation phases
• Around reaction zones and pullback areas
• Near support, resistance, VWAP, or liquidity references
• When evaluating whether a candle has real participation behind it
• When comparing initiative candles against absorption or rejection candles
⚠️ When NOT to Use
• Extremely illiquid markets
• Very noisy low-timeframe environments
• News-driven candles with abnormal spreads
• Symbols with unreliable volume data
• Situations where broader market context is ignored
🎛️ Key Inputs
• Volume Context Length → controls the relative volume comparison window
• Follow-Through Length → controls how short-term continuation is measured
• Initiative Body Ratio → changes how strict the initiative candle filter is
• Reaction Wick Ratio → changes how strict wick-based rejection and absorption filters are
• Visible Zone Bars → controls how much of the recent chart the intent zone covers
• Label and Panel Font Size → controls visual readability
🖥️ Interface & Visual Design
The interface is designed to stay clean, readable, and publication-friendly.
The chart focuses on one main intent zone, compact event labels, right-side context tags, and a structured panel.
The visual hierarchy is intentional: zone first, current state second, historical intent events third.
🧪 Practical Usage Workflow
1. Read the panel to understand the current candle intent state
2. Check the intent zone and its position relative to price
3. Review recent labels to understand whether initiative, absorption, or rejection has dominated
4. Compare the quality score with current follow-through
5. Interpret the output inside broader market context
🔍 Interpretation Guidelines
A strong intent label does not mean price must continue.
A rejection label does not mean reversal is guaranteed.
An absorption label means the candle structure showed reaction and participation, but confirmation still depends on the following market behavior.
The best interpretation comes from combining candle intent with structure, liquidity, volatility, and timeframe context.
🚫 What This Script Is NOT
This script is not a prediction engine.
It is not financial advice.
It is not an auto-trading system.
It does not provide guaranteed buy or sell signals.
It does not replace risk management or independent analysis.
⚠️ Limitations & Transparency
Candlestick interpretation changes across timeframes.
Volume quality may differ between markets and exchanges.
Fast volatility expansion can make recent candle intent less stable.
Low-liquidity conditions may create misleading wick or body readings.
Users should always interpret outputs within broader market context.
🧠 Market Context Notes
Candle intent is most useful when combined with structure, liquidity, trend quality, volatility, and acceptance behavior.
One candle rarely tells the whole story. The value comes from understanding whether candle pressure is supported or rejected by what comes next.
🧾 Use Case Examples
When price reaches a known support area and the script prints a lower rejection label with improving quality, the trader can study whether downside pressure is being rejected.
When a strong body candle prints with high quality and follow-through, the trader can evaluate whether initiative pressure is entering the market.
When absorption appears inside a range, the trader can watch whether trapped pressure develops or fades.
🧱 System Philosophy
Candle Intent Map is part of the AGPro Series approach: clean visual tools that focus on market context, reaction quality, and decision support rather than prediction claims.
The script is designed to make candle behavior easier to read while keeping the trader responsible for interpretation.
🔐 Non-Promise Statement
No script can know the future.
No candle label guarantees continuation or reversal.
This tool provides structured visual context only.
📉 Risk Disclosure
Trading involves risk.
Market conditions can change quickly.
All decisions remain the responsibility of the user.
This script does not provide financial advice or guaranteed trading outcomes.
📚 Educational Note
Use this script as an educational and analytical companion for studying candle behavior, reaction quality, and short-term intent context.
Pine Script® 인디케이터
VWAP Control Shift Map [AGPro Series]VWAP Control Shift Map
🧠 Core Idea
Has VWAP control shifted from mean reversion to directional acceptance?
📌 Overview / What it does
VWAP Control Shift Map is a VWAP control and acceptance visualization tool built to identify when price is balanced around value, accepted above control, accepted below control, or rejected back into the VWAP band.
The script builds a rolling volume-weighted control line, maps a VWAP control band, labels acceptance and rejection events, and summarizes the current VWAP state in a compact AG Pro panel.
This script does not predict future price direction, automate trades, or provide guaranteed buy/sell signals. It is a structured decision-support map for VWAP control, acceptance quality, mean-reversion risk, and shift context.
🎯 Purpose & Design Philosophy
VWAP is one of the most watched value references across intraday and swing trading contexts.
The problem is that price can cross VWAP many times without meaningful control transfer. This script was built to separate casual VWAP interaction from stronger acceptance, rejection, and reversion behavior.
The design philosophy is to make VWAP context visually readable: where control sits, which side is accepted, whether reversion risk is rising, and whether the shift has quality.
⚡ Why This Script Is Different
Most VWAP tools plot a line, add bands, and leave interpretation entirely to the user.
This script does NOT simply mark every VWAP touch as important and does NOT treat every cross as a trend signal.
Instead, it frames VWAP as a control zone: acceptance above, acceptance below, rejection back into value, and mean-reversion risk are all organized into one visual map.
⚙️ Methodology
1. VWAP Control Detection
The script calculates a rolling volume-weighted control line using price and volume over the selected control window.
2. Control Band Mapping
It builds a volatility-adjusted band around VWAP to represent the current value-control area.
3. Acceptance Evaluation
Consecutive closes outside the band are used to identify directional acceptance.
4. Rejection Evaluation
If price returns into the band after a shift, the script marks VWAP rejection behavior.
5. Visual Output
The chart displays the VWAP control line, bordered control zone, centered band label, event labels, right-side state tags, and AG Pro panel.
🗺️ How to Read the Chart
The VWAP control line represents the rolling volume-weighted value reference.
The control band represents the active VWAP acceptance area.
Labels mark acceptance, rejection, and mean-reversion events.
Right-side tags show the current control state and shift quality.
The panel summarizes VWAP control, acceptance state, control side, reversion risk, shift quality, control band, and next context.
🚦 Signals & States
• VWAP BALANCE → price has not established a clear accepted side
• ACCEPT ABOVE → price has accepted above the VWAP control band
• ACCEPT BELOW → price has accepted below the VWAP control band
• VWAP REJECTION → a control shift returned back into the band
• REVERSION RISK → price is back inside the band after a directional control state
🔔 Alerts Logic
VWAP Control Shift Up alert triggers when price accepts above the VWAP control band.
VWAP Control Shift Down alert triggers when price accepts below the VWAP control band.
VWAP Rejection alert triggers when price returns back into the band after a control shift.
Alerts are attention markers. They are not trade instructions.
🧩 Confluence Logic
The context becomes stronger when acceptance direction, VWAP slope, distance from VWAP, and candle body pressure align.
The context becomes weaker when price quickly returns into the control band after an attempted shift.
📊 When to Use
• VWAP-based intraday analysis
• Swing charts where volume-weighted value remains relevant
• Mean-reversion versus directional acceptance decisions
• Markets with liquid volume and clean price structure
• Trend continuation or failed acceptance review
⚠️ When NOT to Use
• Very illiquid symbols
• Markets with unreliable volume
• Extremely noisy low-timeframe charts
• News shock environments where VWAP control changes abruptly
• Any context where a single indicator is being used without broader structure
🎛️ Key Inputs
• VWAP Control Length → controls the rolling volume-weighted control window
• Band Volatility Length → controls how the band width is calculated
• Control Band Multiplier → adjusts VWAP control band width
• Acceptance Bars → defines how many closes are needed for acceptance
• Rejection Window → controls failed-shift timing
• Visual settings → control the panel, zone, labels, font sizes, and projection
🖥️ Interface & Visual Design
The interface is designed for clean, premium chart reading.
The VWAP band uses visible four-edge zone boundaries so the control area remains clear in both editor and published TradingView views.
The panel uses the AG Pro merged blue header standard and keeps the current context readable without covering the main chart.
🧪 Practical Usage Workflow
1. Read the panel state.
2. Check whether price is inside, above, or below the VWAP control band.
3. Review acceptance or rejection labels.
4. Compare shift quality with reversion risk.
5. Use broader market structure before making any decision.
🔍 Interpretation Guidelines
VWAP control is not a prediction.
Acceptance shows where price has spent enough time outside the control band to suggest directional control.
Rejection shows that the attempted control shift returned back toward value.
Mean-reversion risk increases when price moves back into the VWAP control area after directional acceptance.
🚫 What This Script Is NOT
This script is not a prediction engine.
It is not financial advice.
It is not an auto-trading system.
It does not guarantee profitable trades.
It does not replace risk management or independent analysis.
⚠️ Limitations & Transparency
VWAP behavior can vary by timeframe, market session, liquidity, and volume quality.
Rolling VWAP control may differ from exchange-session VWAP or anchored VWAP tools.
Extreme volatility can temporarily reduce the usefulness of control-band interpretation.
Outputs should always be interpreted within broader market context.
🧠 Market Context Notes
VWAP often works as a value reference, but value can shift when acceptance becomes persistent.
A clean control shift is stronger when price accepts outside the band while VWAP slope supports the move.
A weak shift often returns back into the band and becomes a rejection or mean-reversion context.
🧾 Use Case Examples
When price accepts above the VWAP control band with strong shift quality, the chart may be showing directional control above value.
When price accepts below the band and VWAP turns down, the control context may favor downside acceptance.
When price quickly returns into the band after acceptance, VWAP rejection risk becomes more important.
🧱 System Philosophy
AGPro Series tools are built to convert complex market behavior into visual decision maps.
The goal is not certainty. The goal is structured context, cleaner interpretation, and better chart discipline.
🔐 Non-Promise Statement
No script can know the future.
No signal is certain.
No visual state should be treated as a guaranteed outcome.
📉 Risk Disclosure
Trading involves risk.
Markets can move unexpectedly.
Users are responsible for their own decisions, risk management, and trade execution.
This script does not provide financial advice.
📚 Educational Note
This tool is intended for educational and analytical use. It can help traders study VWAP control, acceptance shifts, rejection behavior, and mean-reversion risk.
Pine Script® 인디케이터
Smart Liquidity Map - Institutional MTFSmart Liquidity Map (SLM) - Multi-Timeframe Institutional Orderblocks
Description:
This advanced trading tool generates a fully automated institutional liquidity map directly on your price chart. By scanning key algorithmic levels, it precisely targets institutional resting orders (Buy-Side & Sell-Side Liquidity). Thanks to a smart adaptive script engine, it works perfectly across any chart resolution, maintaining a rock-solid, constant multi-timeframe perspective.
Core Features:
Fixed Multi-Timeframe Matrix (1H, 4H, 1D):
Removes lower-timeframe noise. The indicator strictly tracks the three most critical institutional horizons: 1-Hour, 4-Hour, and Daily pivots.
Smart Confluence Engine (Combo Zones):
When opposing liquidity levels (BSL & SSL) collide within a narrow price threshold, they instantly merge into a highly significant, dark orange Combo Zone .
Overlay & Cluster Aggregation:
If same-direction levels overlap across different timeframes (e.g., 1H BSL + 4H BSL), the chart remains clean. The dynamic label automatically lists all involved timeframes (e.g., BSL ).
Volume Profile POC Box:
Dynamically computes the Point of Control (POC) based on historical volume distribution and renders it as a clean, custom gray box with high-contrast labeling.
Real-Time Sweep Mitigation:
As soon as price sweeps a liquidity level, the zone gets updated instantly (removed or faded) to keep your workspace clean and efficient.
Visual Color Guide:
Red: Pure Buy-Side Liquidity (BSL) – Resistance / Short Targets.
Green: Pure Sell-Side Liquidity (SSL) – Support / Long Targets.
Orange: Mixed Combo Zones (BSL + SSL Confluence).
Gray: Volume Profile Point of Control (POC).
Pine Script® 인디케이터
Confluence S/R Engine MTF Strength Map [MLI]# Confluence S/R Engine — Multi-TF Strength Map
A multi-method, multi-timeframe support and resistance zone indicator designed to identify price areas where multiple independent market structure signals overlap.
The script combines structural, volumetric, and higher-timeframe reference levels into composite zones and assigns each zone a relative strength score from 0–10 based on confluence factors such as method diversity, timeframe participation, recency, and cluster tightness.
This indicator is intended to provide a visual map of potentially relevant market structure areas. It does not generate buy/sell signals or provide trading advice.
---
## Features
* Multi-timeframe support and resistance zone mapping
* Composite confluence scoring system
* Anchored VWAP integration
* Anchored Volume Profile POC / VAH / VAL levels
* Multi-timeframe pivot structure
* Fibonacci VWAP deviation bands
* Naked POC tracking
* Absorption-style candle detection
* Dynamic zone rendering with opacity scaled by score
* Snapshot table summarizing current zone state
* Optional automatic lookback scaling by chart timeframe
---
## Methods Included
### Tier A
* Anchored Volume Profile POC
* Naked POCs
* Institutional-style anchor candle highs/lows
* Absorption-anchor candle H/L/C
* Higher-timeframe VP-POCs
### Tier B
* Value Area High / Low
* Native swing extremes
* Anchored VWAP
* Fibonacci 0.618 VWAP bands
### Tier C
* Multi-timeframe pivot highs/lows
### Tier D
* AVWAP ±1σ bands
* Fibonacci 0.382 bands
* Prior swing references
### Tier E
* AVWAP ±2σ bands
* Fibonacci 1.0 bands
* Higher-timeframe closes
---
## Zone Scoring
Each zone is evaluated across multiple dimensions:
* Level quality
* Method diversity
* Timeframe diversity
* Recency
* Cluster tightness
Zones are scored on a 0–10 scale to help visually compare relative confluence strength.
---
## Visual Interpretation
* Green zones: support-oriented regions
* Red zones: resistance-oriented regions
* Yellow-green zones: higher-strength support clusters
* Yellow-orange zones: higher-strength resistance clusters
Higher-opacity zones represent stronger composite scores.
---
## v2.3 Updates
* Added automatic timeframe-based lookback scaling
* Added institutional-style snapshot table
* Improved rendering and internal optimization routines
* Reduced redundant calculations and cleaned rendering flow
---
## Notes
This script is designed as a chart-analysis tool and should be used alongside individual risk management and independent market analysis.
No indicator can predict future price movement with certainty.
---
## Disclaimer
For educational and informational purposes only.
This script does not constitute financial advice, investment advice, or a recommendation to trade any financial instrument. Trading involves risk, and users are solely responsible for their own decisions and risk management.
Pine Script® 인디케이터
TradeCraftly - Simple VWAPTradeCraftly - Simple VWAP is a clean, lightweight, and highly optimized Volume Weighted Average Price (VWAP) indicator designed for intraday traders and scalpers who prefer a minimal yet effective trading setup.
Unlike complex VWAP implementations filled with unnecessary calculations and overlays, this script focuses on speed, clarity, and usability while maintaining accurate session-based VWAP tracking.
Key Features:
• Accurate Session VWAP calculation
• Clean and distraction-free chart display
• Customizable VWAP color and line thickness
• Dynamic live VWAP label on the latest candle
• Lightweight and optimized Pine Script v6 code
• Suitable for scalping, intraday, and trend-following strategies
How Traders Use It:
• Identify intraday trend direction
• Detect premium and discount price zones
• Find dynamic support and resistance areas
• Spot potential mean reversion opportunities
• Confirm momentum and institutional price bias
Typical Interpretation:
• Price above VWAP → Bullish intraday sentiment
• Price below VWAP → Bearish intraday sentiment
• Reactions near VWAP may indicate continuation or reversal zones
This indicator is built for traders who value simplicity, fast chart performance, and practical decision-making without unnecessary visual clutter.
Pine Script® 인디케이터
Volume Participation Shock Map [AGPro Series]Volume Participation Shock Map
🧠 Core Idea
Did the volume shock bring real participation, or did the move get absorbed after the first impulse?
📌 Overview / What it does
Volume Participation Shock Map is a volume-flow interpretation tool designed to study what happens after a major participation candle appears.
The script identifies high-quality volume shocks by combining relative volume, candle body participation, ATR-adjusted range expansion, and close location. It then projects the active shock zone, tracks follow-through, detects absorption risk, highlights thin continuation attempts, and summarizes the current participation state in an AG Pro panel.
It does not predict price direction, automate trades, or claim that every high-volume candle will continue. It is a structured visualization tool for reading participation quality after volume events.
🎯 Purpose & Design Philosophy
Many volume tools stop at the first spike.
This script was built to answer the next question:
Did the market continue to participate after the shock, or was the impulse absorbed?
The design goal is to help traders separate meaningful volume expansion from one-bar excitement, thin breakouts, and failed participation.
⚡ Why This Script Is Different
Most tools focus on volume spikes, climax candles, or simple high-volume alerts.
This script does NOT treat high volume as automatically bullish or bearish.
Instead, it checks whether the candle had real body participation, whether price followed through beyond the shock zone, whether the move was absorbed back through the zone, and whether later breakouts happened with weak participation.
⚙️ Methodology
1. Shock Detection
The script compares current volume with recent average volume, checks candle body share, evaluates ATR-adjusted range expansion, and scores close location.
2. Shock Zone Mapping
When a qualified shock appears, the candle range becomes an active participation shock zone.
3. Follow-Through Evaluation
After the shock, the script watches whether price accepts beyond the shock high or low with enough relative volume.
4. Absorption Evaluation
If price closes back through the shock zone after the impulse, the script can mark absorption risk.
5. Visual Output
The chart displays the active shock zone, midpoint participation rail, event labels, right-side context tags, alerts, and a compact AG Pro panel.
🗺️ How to Read the Chart
Participation Shock Zone = the active high-volume candle range being evaluated.
Participation Rail = the midpoint of the shock zone.
BULL VOLUME SHOCK = a bullish shock candle with strong volume, body participation, and range expansion.
BEAR VOLUME SHOCK = a bearish shock candle with strong volume, body participation, and range expansion.
REAL FLOW CONTINUATION = price followed through beyond the shock zone with acceptable participation.
ABSORPTION RISK = price moved back through the shock zone after the initial impulse.
THIN MOVE = price moved beyond the shock edge without enough relative volume. This appears in Detailed label mode.
Panel = summarizes participation state, quality score, shock type, relative volume, body participation, follow-through, absorption risk, and next context.
🚦 Signals & States
• BULL VOLUME SHOCK → bullish high-participation impulse appeared.
• BEAR VOLUME SHOCK → bearish high-participation impulse appeared.
• REAL FLOW UP → bullish shock followed through with acceptable participation.
• REAL FLOW DOWN → bearish shock followed through with acceptable participation.
• BULL SHOCK ABSORBED → bullish shock lost participation back through the zone.
• BEAR SHOCK ABSORBED → bearish shock lost participation back through the zone.
• SHOCK WATCH → an active shock is still being evaluated.
• QUIET FLOW → no active participation shock is currently dominant.
🔔 Alerts Logic
Alerts trigger when a major participation state appears.
• Volume Participation Shock → a high-quality volume shock appears.
• Real-Flow Continuation → price follows through beyond the active shock zone with acceptable participation.
• Absorption Risk → price closes back through the active shock zone after the shock.
• Thin Move → price moves beyond the shock edge without enough relative volume.
Alerts are attention markers, not trade instructions.
🧩 Confluence Logic
The context becomes stronger when:
• Relative volume is clearly above normal
• Candle body participation is strong
• Candle range expands versus ATR
• Price closes near the directional side of the candle
• Follow-through appears before the evaluation window expires
• The panel state agrees with the chart label
If these elements do not align, the script avoids treating volume as automatic conviction.
📊 When to Use
• Breakout participation review
• Trend continuation validation
• Reversal impulse analysis
• High-volume candle interpretation
• Futures, stocks, forex, crypto, and liquid markets
• 15m, 30m, 1H, 4H, and 1D charts where volume data is meaningful
⚠️ When NOT to Use
• Symbols with unreliable or missing volume data
• Very low-liquidity markets
• Extremely noisy micro timeframes
• News spikes where volume behavior may be abnormal
• Markets where candle volume does not represent real participation well
• Situations where a single volume event should not be over-interpreted
🎛️ Key Inputs
• Relative Volume Length → defines the volume baseline.
• Shock Relative Volume → sets how strong volume must be before a shock can qualify.
• Minimum Body Participation % → controls how much candle body commitment is required.
• Minimum Range ATR → filters out small candles with high volume.
• Shock Quality Threshold → controls how selective the main shock labels are.
• Follow-Through Window → defines how long after a shock the script watches for continuation or absorption.
• Minimum Follow Relative Volume → defines whether continuation has enough participation.
• Absorption Midline Threshold % → controls how deeply price must return into the shock zone before absorption risk is marked.
• Event Label Mode → Premium focuses on major shock, continuation, and absorption events. Detailed also allows thin-move labels.
🖥️ Interface & Visual Design
The visual hierarchy is built around the active shock zone.
The zone shows the high-volume impulse range.
The midpoint rail helps judge acceptance versus absorption.
Event labels highlight the most important participation behavior.
Right-side tags keep the current shock context visible.
The AG Pro panel compresses the current state into a fast, readable decision-support summary.
🧪 Practical Usage Workflow
1. Read the panel participation state.
2. Check whether an active shock zone is present.
3. Watch whether price accepts beyond the shock high or low.
4. Evaluate whether follow-through has enough relative volume.
5. Watch for absorption back through the shock zone.
6. Confirm the chart context with structure, trend, liquidity, and risk planning.
🔍 Interpretation Guidelines
A volume shock is not automatically a valid trade signal.
Continuation is stronger when price accepts beyond the shock zone with participation.
Absorption matters when the first impulse cannot hold its zone.
Thin moves can warn that price is extending without enough participation.
The script is best used as a participation-reading layer, not as a standalone decision system.
🚫 What This Script Is NOT
This script is not a prediction engine.
It is not financial advice.
It is not an auto-trading system.
It does not provide guaranteed entry or exit signals.
It is not a simple volume spike alert.
⚠️ Limitations & Transparency
Volume quality depends on the symbol and market.
Crypto, futures, stocks, and forex may represent volume differently.
High volatility can create sudden shock labels that need broader context.
Low-liquidity assets may produce misleading relative volume readings.
Different timeframes may show different participation behavior.
🧠 Market Context Notes
Volume can be useful only when it is read together with price behavior.
A strong candle with high volume may show participation.
But if price cannot follow through, that same candle may become an absorption reference.
This script is designed to make that difference easier to see.
🧾 Use Case Examples
If a strong bullish candle appears with high relative volume, large body participation, and range expansion, the script may mark BULL VOLUME SHOCK.
If price later closes above the shock high with enough participation, the script may mark REAL FLOW CONTINUATION.
If price closes back through the shock zone after the impulse, the script may mark ABSORPTION RISK.
If price breaks beyond the shock edge with weak relative volume, Detailed mode may mark THIN MOVE.
🧱 System Philosophy
The goal is not to make volume louder.
The goal is to make volume behavior more interpretable.
This script treats participation as a sequence:
shock → acceptance → follow-through → absorption or continuation.
🔐 Non-Promise Statement
No script can guarantee market direction.
No volume event guarantees continuation.
No absorption label guarantees reversal.
All outputs should be interpreted as analytical context.
📉 Risk Disclosure
Trading involves risk.
This script is for educational and analytical purposes only.
It does not provide financial advice, investment advice, or guaranteed trading outcomes.
Users are fully responsible for their own decisions, risk management, and trade execution.
📚 Educational Note
Use the script to study how markets behave after high-participation candles.
The most important question is not only whether volume appeared.
The better question is whether price continued to accept that participation afterward.
Pine Script® 인디케이터
AI SMC Pro v2AI SMC Order Flow Pro v2.0 is an advanced Smart Money Concepts indicator combining ICT methodology, multi-timeframe analysis, Bayesian AI scoring, and order flow estimation — all in a single non-repainting overlay.
Core Features:
BOS & CHoCH structure detection
Bullish & Bearish Order Blocks (auto-invalidation)
Fair Value Gaps (auto-fill detection)
Liquidity levels (LQH / LQL)
Premium & Discount zones
Session High/Low (Asia, London, New York)
Support & Resistance (50-bar dynamic)
AI Engine:
Bayesian confidence score (0–100%) combining trend, momentum, MACD, volume, structure, order flow, MTF bias, session and zone
Three modes: Conservative / Balanced / Aggressive
Order Flow Module:
Estimated buy/sell pressure
Estimated delta & cumulative delta
Volume spike detection
Signals:
LONG / SHORT entries with SL, TP1, TP2
ATR-based risk management (customizable multipliers)
Minimum R:R filter (1:2 / 1:3 / 1:4)
Session filter (London & New York only)
MTF confirmation required
Built-in Backtest:
Win rate, Profit Factor, Expectancy
Max win/loss streak
Trailing stop & Break-even options
Best used on: EUR/USD · GBP/USD · 15m timeframe during London or New York session.
Pine Script® 인디케이터
Buy and Sell Candle PressureBuy and Sell Candle Pressure takes the candle-pressure model used in my closed-source script "Predictive Volume MTF Pro" workflow and brings that Buy/Sell pressure read directly onto the price chart. Instead of viewing the Buy/Sell split only inside a table, the candles themselves can now show whether the active candle structure is leaning bullish, bearish, neutral, or moving through stronger pressure tiers.
The goal is simple:
• keep the real OHLC candle shape intact
• recolor the candle body, wick, and border from the candle-pressure engine
• make candle-by-candle pressure easier to see directly on the chart
• add local and higher-timeframe bias trails for extra context
This is not meant to replace the main Predictive Volume dashboard. It is meant to be a lightweight visual companion that helps bring the Buy/Sell pressure read into your chart space.
────────────────────────────
What the Candle Colors Represent
────────────────────────────
The candle overlay uses a candle-structure pressure estimate built from OHLC and volume behavior.
The pressure model looks at more than just whether a candle closed green or red. It considers:
• where the close sits inside the full candle range
• how much directional conviction is shown by the candle body
• how upper and lower wicks may reflect rejection, absorption, or imbalance
That pressure score is then converted into a rounded Buy/Sell split and used to color the candle overlay.
Important:
This is not true order flow, bid/ask volume, or exchange-level volume delta. It is a candle-structure pressure estimate designed to give visual context from the candle itself.
────────────────────────────
Bias Modes
────────────────────────────
The script includes two candle color modes:
Standard
A simple bull / bear / neutral color mode.
This is the cleanest option if you only want to know whether the candle-pressure read is leaning toward buy pressure, sell pressure, or balance.
Standard II
A stronger tiered color mode.
This mode expands the Buy/Sell pressure split into multiple bull and bear intensity levels. Lighter colors represent earlier pressure development, while stronger colors represent more aggressive Buy/Sell pressure readings.
────────────────────────────
Pressure Bias Trail
────────────────────────────
The Pressure Bias Trail is a rolling price-bias reference line designed to pair with the pressure candles.
In plain terms:
• candles show current-bar Buy/Sell pressure
• the Pressure Bias Trail shows the local rolling price-bias reference
The trail is calculated from the selected price source, average type, and length. Its color is based on whether the current close is above or below the trail.
This gives the chart two layers of context:
• candle pressure = what the current candle is showing
• trail position = whether price is holding above or below its rolling bias reference
────────────────────────────
HTF Pressure Bias Trail
────────────────────────────
The HTF Pressure Bias Trail applies the same trail formula on an automatically selected higher timeframe.
The HTF value is stabilized using SimpleCryptoLife’s HighTimeframeSampling library so the higher-timeframe trail behaves more smoothly on the active chart timeframe.
This can help users compare:
• current candle pressure
• local rolling price bias
• higher-timeframe rolling price bias
When price is above both the local and HTF trails, the chart can show stronger alignment. When price is trapped between them, fading through one, or repeatedly rejecting one, the trails can provide useful context around pressure transitions.
────────────────────────────
Included Visual Tools
────────────────────────────
• Buy/Sell Pressure Candle Overlay
• Standard and Standard II pressure color modes
• Chart-timeframe Pressure Bias Trail
• HTF Pressure Bias Trail
• Bar-to-Bar Close Follow Line
• Last-Bar Index Follow Line
• Last-Bar Buy/Sell + Pressure Label
The pressure label shows the rounded Buy/Sell split on the first line and the normalized pressure value on the second line. It can auto-position above bullish pressure and below bearish pressure.
────────────────────────────
How I Use It
────────────────────────────
I view this script as a chart-side pressure layer.
The main Predictive Volume + MTF script gives the broader table-based multi-timeframe volume view. This script brings one important part of that workflow — candle pressure — directly onto the candles.
Useful ways to read it:
• Standard II candles can highlight stronger Buy/Sell pressure tiers
• the local Pressure Bias Trail can show whether price is holding its short-term bias
• the HTF Pressure Bias Trail can show where higher-timeframe bias may be acting as context
• the pressure label gives a quick last-bar read without needing a full table
This is not a buy/sell signal system by itself. It is a visual context tool.
────────────────────────────
Companion Script
────────────────────────────
This script is designed to work hand in hand with:
Predictive Volume + MTF
Predictive Volume + MTF remains the larger dashboard-style workflow for multi-timeframe predictive volume, current volume, previous volume, average volume, relative volume, and Buy/Sell pressure context.
Buy and Sell Candle Pressure is the lightweight open-source candle-overlay companion.
────────────────────────────
Attribution
────────────────────────────
Special thanks to SimpleCryptoLife for the original Predictive Volume foundation and for the HighTimeframeSampling library used to stabilize the HTF Pressure Bias Trail.
This open-source script is published as a companion visualization layer for "Predictive Volume + MTF ".
Pine Script® 인디케이터
Volume Run RateVolume Run Rate
What it does
This indicator answers a simple question that raw volume bars can't: "At this point in the trading day, are we trading more or less than usual?"
It accumulates volume from the start of each day, expresses that running total as a percentage of the average full-day volume over a lookback window, and then compares the current reading to where the run rate typically sits at the same time of day historically. When today's pace pushes meaningfully above that historical norm (default: more than 2 standard deviations), the background highlights yellow.
Three lines are plotted:
Green stepline — today's cumulative volume so far, as a % of the average daily total over the lookback window.
Gray line — the average run rate at this same time-of-day across the lookback days.
Orange crosses — the upper threshold (historical same-time mean + N standard deviations). When the green line breaks above it, the day is participating unusually heavily for this point in the session.
Why intraday cumulative volume vs. history beats looking at volume alone
A single volume bar tells you only what happened in the last 5 minutes (or 15, or whatever your timeframe is). That's a noisy, low-context signal. Volume is naturally lumpy intraday — the open and close are always heavy, lunch is always thin — so a "big" bar at 10:00 might be completely normal, and a "small" bar at 14:30 might actually be elevated for that time slot. Eyeballing bar height tells you almost nothing about whether real interest is building.
Cumulative volume from the day's open smooths out that bar-to-bar noise and captures a more meaningful quantity: how much total participation has shown up so far today. But "a lot" or "a little" only means something when measured against a baseline. Comparing today's cumulative volume at 11:00 to the typical cumulative volume at 11:00 over the last 20 days gives you a like-for-like read on whether today is unusually busy for where we are in the session. Two standard deviations above that historical mean is statistically rare — roughly the top 2-3% of historical readings at this time slot — which is why it's a useful alert level.
How to use it
Volume tends to confirm or contradict price moves. The run rate makes that confirmation legible in real time:
Breakout validation. Price breaks a key level intraday and the run rate is already running hot above the threshold — participation is real, the move has fuel behind it. Same breakout on a depressed run rate is much more likely to fail or fade.
Trend day vs. chop day, early. If the run rate pushes through the upper threshold in the first hour or two, the day is on track for an above-average volume session, which historically correlates with directional follow-through. A run rate stuck near or below the historical average suggests a low-conviction, mean-reverting tape — fade the edges, don't chase.
News and event reaction. When something hits the tape, the question isn't "did volume go up" (it almost always does for one bar) but "is the market actually engaging with this." A run rate that gaps above the threshold and stays there says yes. A spike that immediately reverts says the market dismissed it.
Distribution and accumulation timing. Sustained elevated run rate at a price plateau, especially near prior highs or lows, suggests something larger going on than the price action alone reveals.
Avoiding low-conviction setups. If your trade thesis depends on participation but the run rate is well below average for this time of day, that's a real signal to size down or skip.
Inputs
Lookback days — how many prior days to use as the historical baseline. Default 20 (≈ one trading month).
Std Dev threshold — how many standard deviations above the historical same-time mean triggers the elevated-volume background. Default 2.0.
Exclude weekends — turn on for crypto or other 24/7 markets where weekend sessions have structurally different volume profiles than weekdays. Off by default (correct for traditional Mon-Fri markets).
Notes
Use on intraday timeframes only (anything lower than Daily). On Daily or higher, an error message is shown — the "cumulative vs. history at the same time of day" comparison only makes sense within a day.
The indicator stores every intraday bar's run rate in persistent arrays, which lets it look back further than Pine's standard 5000-bar history limit and compare apples to apples across the full lookback window.
The historical comparison uses the bar's position within the day (1st bar, 2nd bar, etc.), so it works on any intraday timeframe automatically.
Pine Script® 인디케이터
Effective Volume (Weighted by candle pattern)This is a indicator using candle : wick ratio to obtain a weighted volume.
useful for trader using volume-price action strategy.
the mechanism is easy:-
when it is full bullish / full bearish bar, the weighted volume exactly equal to the volume itself.
when it is a total wick bar , the weighted volume will be half of that time-frame volume
the weighted formula is simple mathematics due to body : wick ratio.
However, I find that it useful for me.
Pine Script® 인디케이터
SMC Supply & Demand Zones - H4 / H1 / M10Automatically identifies and draws supply and demand zones across three timeframes (H4, H1, and M10) simultaneously on any chart, using a strict volume-confirmed impulse candle definition rooted in Smart Money Concepts (SMC).
How zones are built
A zone is created only when all three conditions are met on the same candle:
Body size ≥ 1.5 × ATR(14) — filters out indecision candles
Close breaks beyond the prior 5 candles' high (demand) or low (supply) — confirms impulsive intent
Volume ≥ 1.5 × SMA(volume, 20) — requires institutional-level participation
Zone boundaries follow the SMC base candle rule: demand zones span from the impulse candle's open down to its low; supply zones span from its high down to its open.
Visual design
Each timeframe uses a distinct colour family so you can read confluence at a glance — H4 in blue, H1 in orange, M10 in green. Lighter shades mark demand, darker shades mark supply. When price closes fully through a zone, it fades to grey and is tagged with (mitigated) — it stays on the chart for context but is visually de-emphasised. Each zone carries a label (e.g. "H4 D", "H1 S") pinned to its right edge.
Settings
Toggle each timeframe on/off independently
Adjust the body multiplier, prior-bar lookback, and volume multiplier to match the instrument
Set separate caps for active and mitigated zones per timeframe (FIFO — oldest removed first)
Full colour control per timeframe and direction
Toggle labels and borders separately
Non-repainting
All three timeframe feeds use request.security() with lookahead = barmerge.lookahead_off and gaps = barmerge.gaps_off. Zones are created only on the bar where an impulse candle's close is first confirmed — no bar-0 data is used.
Recommended use
Load on your entry timeframe (M10 or M5) and use the H4/H1 zones as bias and confluence levels. Look for price to sweep into a higher-TF zone and react — that is your area of interest for entry confirmation on the lower timeframe.
Pine Script® 인디케이터
Forum Initium + LTA Session Breaks (Merged)🟡 LTA ALL-IN-ONE INDICATOR
Pine Script v6 | TradingView | Free to Use
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Built around the Lorenzo Trading Academy
methodology. Combines 5 core concepts
into a single clean indicator so you
never need to juggle multiple tools.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
WHAT IT PLOTS:
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📍 FORUM INITIUM (FI)
→ Auto-detects the Sunday weekly open
every single week — no manual input
→ Draws a gold line as your weekly
bias anchor
→ Live table shows if price is ABOVE
(bullish) or BELOW (bearish) FI
→ Background highlights when price
is within 5 pts of FI level
→ Updates automatically every Sunday
📊 PREVIOUS WEEK HIGH / LOW
→ PWH and PWL plotted automatically
→ Key structural reference levels
→ Labelled on the right of your chart
🕒 SESSION BREAK MARKERS
→ Vertical dotted lines at every
daily session open
→ Separate dashed line at NY 18:00
(weekly session reference point)
→ All fully toggle-able
📈 CURRENT WEEK VOLUME PROFILE
→ Auto-calculates POC, VAH and VAL
for the current live week
→ 128 row resolution (LTA standard)
→ 70% Value Area (LTA standard)
→ Value area shaded automatically
📉 PREVIOUS WEEK VOLUME PROFILE
→ Same levels for last week
→ POC, VAH, VAL all plotted
→ Dashed style to separate from
current week visually
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
BUILT-IN ALERTS (12 total):
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⬆️ Price crosses ABOVE Forum Initium
⬇️ Price crosses BELOW Forum Initium
⚠️ Price approaching FI (within 5 pts)
🎯 Price touching FI level
🗓️ New week opened — FI set
⬆️ Above / ⬇️ Below CW POC
⬆️ Above / ⬇️ Below PW POC
⬆️ Above CW VAH (breakout mode)
⬇️ Below CW VAL (breakdown mode)
🕕 NY 18:00 session marker
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
EVERYTHING IS TOGGLE-ABLE:
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
→ Turn any layer on or off
→ Change all colours to your preference
→ Adjust line widths
→ Change value area % and row count
→ Works on any timeframe
→ Best used on 5M and 1M charts
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
COMPATIBLE WITH:
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
✅ XAUUSD (Gold) — primary use case
✅ Forex pairs
✅ Indices (US30, NAS100, GER30)
✅ Crypto (BTCUSD etc)
✅ TradingView Essential plan or above
✅ Pine Script v6
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
HOW TO INSTALL:
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
1. Open TradingView → Pine Editor
2. Select All (Ctrl+A) → Delete
3. Paste the full script
4. Save (Ctrl+S)
5. Click Add to Chart
6. Set your alerts via Right Click
→ Add Alert on indicator
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Not a signal tool — a confluence tool.
Use it to identify your key levels,
then apply your own entry process.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Pine Script® 인디케이터
Volume Spike Aftershock Planner [AGPro Series]Volume Spike Aftershock Planner
🧠 Core Idea
After a volume spike, is price actually defending the impulse, absorbing it, or losing control completely?
📌 Overview / What it does
Volume Spike Aftershock Planner is designed to evaluate what happens after an abnormal volume expansion candle appears on the chart. Instead of stopping at the spike itself, the script studies the post-impulse behavior and organizes that structure into a readable decision-support framework.
The script maps a spike anchor, an active aftershock band, a failure boundary, and a target-room reference. It also produces contextual labels, right-side price tags, and a compact information panel that summarizes the current aftershock condition with a rule-based score.
This script does not attempt to predict the next candle, automate entries, or generate guaranteed continuation signals. It is an analytical visualization tool that helps users judge whether the spike is still being respected, partially absorbed, or fully invalidated.
🎯 Purpose & Design Philosophy
This script was built to solve a common gap in volume analysis.
Most traders can see when volume suddenly expands. The harder question is what to do with that information after the impulse bar closes. A large volume candle can lead to continuation, rejection, absorption, or complete failure, and those outcomes do not deserve the same interpretation.
This tool helps traders who want a more structured way to read post-spike behavior. It supports a patient, evidence-based mindset by focusing on participation quality, impulse defense, failure thresholds, and available room rather than hype or prediction.
⚡ Why This Script Is Different
Most volume tools focus on spike detection, raw histogram expansion, or one-bar climax alerts.
This script does NOT stop at identifying unusual participation.
Instead, it tracks the aftershock environment that forms after the spike, measures whether price is holding the impulse anchor, maps when the move is being absorbed, and highlights when the context has either matured or failed. The result is not just a volume event marker, but a structured framework for interpreting what the spike still means.
⚙️ Methodology
1. Context Detection
The script scans for abnormal volume participation and range expansion relative to recent behavior. It also reviews body quality so that weak, indecisive candles are filtered more carefully.
2. Reference Mapping
Once a valid spike is confirmed, the script establishes a spike anchor and builds an aftershock band around that reference. It also defines a failure boundary and a room projection.
3. Reaction Evaluation
Price is then evaluated relative to the anchor and surrounding rails. The script checks whether the impulse is being defended, fading back through the anchor, or failing beyond the allowed structure.
4. Visual Output
The final output includes the aftershock band, anchor reference, room line, failure line, event labels, right-side tags, optional bar coloring, and a dashboard panel that summarizes the current state.
🗺️ How to Read the Chart
Zones:
The aftershock band represents the active post-spike area where the market is being evaluated. It is the main structure zone for interpreting whether the impulse still matters.
Labels:
Labels mark important contextual events such as bull spike, bear spike, holding behavior, absorbed behavior, target review, and failure.
Colors:
Teal highlights constructive bullish behavior or defended impulse structure.
Pink highlights bearish structure, invalidation, or failed context.
Gold highlights review areas such as absorption or target-room interaction.
Indigo highlights the spike anchor reference.
Panel:
The panel summarizes the spike state, the Aftershock Score, participation quality, available room, and the current action state.
🚦 Signals & States
• Bull Spike → A bullish high-participation impulse anchor has been detected.
• Bear Spike → A bearish high-participation impulse anchor has been detected.
• Holding → Price is still defending the impulse structure after the spike.
• Aftershock Ready → The post-spike condition is strong enough to deserve active attention.
• Absorbed → Price has moved back through the anchor and the impulse is losing control.
• Target Review → The projected first room objective has been reached and context should be reassessed.
• Failed → The active aftershock structure has broken down beyond the allowed limit.
• Wait Spike → No valid active spike context is currently available.
• Expired → The spike is too old to remain actionable within the current framework.
🔔 Alerts Logic
Alerts can trigger when a new bullish or bearish spike is detected, when price begins to hold the impulse, when the aftershock condition becomes ready, when the move becomes absorbed, when target room is reached, or when the context fails.
These alerts are attention markers only. They highlight a structural event inside the script logic. They are not trade instructions, automated entries, or guarantees of follow-through.
🧩 Confluence Logic
The context becomes stronger when multiple conditions align at the same time.
For example, a high relative-volume spike with strong candle expansion, defended anchor structure, stable participation decay, and clear room beyond the band creates a much stronger environment than a spike that immediately collapses back through its reference level.
This confluence logic is what separates a meaningful aftershock structure from a noisy one-bar event.
📊 When to Use
• Markets with reliable volume behavior
• Crypto pairs with clean participation swings
• Stocks and indices with readable impulse candles
• Breakout or breakdown follow-through evaluation
• Continuation review after a strong reaction candle
• 1H, 4H, and 1D chart studies where impulse quality matters
⚠️ When NOT to Use
• Illiquid symbols with distorted or unreliable volume
• Extremely noisy low-range environments
• Symbols where volume feed quality is poor
• Isolated one-bar anomalies with no structural follow-through
• Extreme volatility conditions where impulse rails become unstable too quickly
🎛️ Key Inputs
• Relative Volume Length → Controls the participation baseline used for spike comparison.
• Minimum Relative Volume → Controls how large the volume expansion must be before the candle qualifies as a spike.
• Minimum Range Ratio → Controls how much price expansion is required.
• Minimum Body Ratio → Filters out weak spike candles with poor body commitment.
• Aftershock Band ATR → Controls the depth of the active aftershock zone.
• Failure Buffer → Controls how far price can move before the spike idea is considered broken.
• Minimum Ready Score → Controls how strict the script is before showing stronger actionable states.
• Visual Settings → Control labels, panel location, theme, font size, and optional chart styling.
🖥️ Interface & Visual Design
The visual design is built around clarity at first glance.
The panel gives a fast structural summary without forcing the user to inspect every line manually. The chart layer uses premium contrast and a clear hierarchy so the aftershock band, anchor, failure boundary, and room references remain readable without overwhelming the candles.
The goal is not decoration. The goal is clean interpretation under live market conditions.
🧪 Practical Usage Workflow
1. Read the panel to understand the current spike state and score.
2. Check whether a valid spike anchor and aftershock band are active.
3. Evaluate whether price is holding, absorbed, or failing relative to the anchor.
4. Review available room and decide whether the current context is mature, early, or already extended.
5. Use labels and tags as structured context markers, not as automatic commands.
🔍 Interpretation Guidelines
Treat the script as a structured reading framework.
A stronger score suggests that the spike had better participation, cleaner range expansion, and more stable post-spike structure. A weaker score suggests that the move may be losing informational value.
An absorbed state does not mean reversal is guaranteed. It means the original impulse is no longer being defended as cleanly as before.
A target-review state does not mean the move must stop. It means the first projected room objective has already been reached and the user should reassess the context rather than assuming endless continuation.
🚫 What This Script Is NOT
This script is not a prediction engine.
It is not a financial advice tool.
It is not an automated trading system.
It is not a broker integration.
It does not place orders.
It does not guarantee continuation, reversal, or profitability.
⚠️ Limitations & Transparency
This script is rule-based and depends on the quality of the underlying market data.
Timeframe changes can materially alter how spikes, bands, and room projections appear. High-volatility environments can also reduce the stability of post-spike structures. In thin or distorted markets, volume expansion may look meaningful while carrying very little analytical value.
The script should always be interpreted in broader market context rather than in isolation.
🧠 Market Context Notes
Volume spikes are often strongest when they appear at meaningful structure transitions, liquidity shifts, or expansion points where the market is forced to reveal intent.
That said, not every spike represents sustainable conviction. Some are exhaustion bursts, some are absorption events, and some are temporary reactions inside a larger opposing structure. The aftershock behavior is often more important than the spike itself.
🧾 Use Case Examples
Example 1:
Price breaks above a local range with a large bullish volume surge. The script marks a bull spike, price holds above the anchor, and the panel shifts into a stronger aftershock state. This suggests the impulse still deserves attention.
Example 2:
Price prints a large bearish impulse, but then quickly moves back through the anchor. The script shifts into an absorbed condition, signaling that the original downside impulse is losing control.
Example 3:
A high-volume move expands sharply, then reaches the target-room area. The script marks target review, reminding the user to reassess the move rather than assuming continuation is still efficient.
🧱 System Philosophy
AGPro Series tools are designed as decision-support frameworks, not signal vending machines.
The philosophy is simple: map structure clearly, make states readable, reduce noise, and help the user think better around live price behavior.
🔐 Non-Promise Statement
This script does not promise certainty.
It does not promise that a volume spike will continue, reverse, hold, or fail in any predetermined way. It simply organizes the available structure so the user can evaluate the situation with more clarity.
📉 Risk Disclosure
Trading and investing involve risk.
Market conditions can change quickly, and any analytical tool can produce outputs that become invalid under new volatility, liquidity, or structural conditions. Users remain fully responsible for their own decisions, risk management, and execution.
This script is provided for educational and analytical purposes only. It is not financial advice.
📚 Educational Note
This tool is most useful when treated as a market-reading assistant.
The best results usually come from combining it with broader structure analysis, liquidity awareness, and disciplined risk management rather than using it as a standalone trigger system.
Pine Script® 인디케이터
Liquidity Grab Detector v4What is this and why do you need it?
The indicator shows where the market maker is hunting stops and when the price is likely to reverse afterwards.
The logic is simple: before a reversal, price often sweeps beyond a key level, takes out retail traders’ stop-losses, and then reverses back. This is called a Liquidity Grab. LGD v4 detects these moments and evaluates the quality of each signal from 0 to 100.
What you see on the chart
Colored zones — Liquidity pools where stops have accumulated. The more touches, the more stops are sitting there.
Signal label (e.g. REJ 72 or ABS 85) — The word is the reversal type, the number is the signal quality (0–100).
Green/Red background — The system is “armed” and waiting for confirmation to enter.
TP and SL lines — Appear only on a valid signal. SL is always placed behind the probe extreme, not on the level itself.
Four Types of Signals
A+ (85–100) — Rare, enter with full size
A (70–84) — Strong signal
B (50–69) — Good, use with additional confirmation
C (<50) — Skip or only in perfect context
TypeIn Simple TermsShould You Enter?ABS (Absorption)A big player absorbed all the pressure with a wall of ordersYes, full sizeREJ (Rejection)Sharp rejection — nobody wanted to continue buying/sellingYes, full sizeDIV (Divergence)Came in with volume but couldn’t holdHalf sizeEXH (Exhaustion)Quiet sweep on low volume, unclear strengthBetter to skip
Simple Entry Algorithm
Check the 1H chart — what’s the daily bias (up or down)?
Check the 5M chart — is LGD showing a signal in the same direction?
Is the signal type ABS or REJ with score above 60?
Place SL where the red box is, and TP at the next liquidity zone.
If any of these conditions aren’t met — skip the trade.
Best Trading Times
Trade Tuesday to Thursday, during the window 09:45–11:30 ET.
Avoid trading on NFP, FOMC, and CPI days — signals are unreliable during high-impact news.
What the Indicator Does
LGD v4 is a liquidity sweep detector for CME micro-futures. It combines three independent engines:
Pool Engine — Creates dynamic liquidity pools from swing highs/lows with a full lifecycle: birth → touches → sweep → death.
Sweep Scoring — Evaluates every sweep using 11 different criteria (0–100 score) and determines the type of reversal.
SFP Trigger Engine — AVWAP exhaustion + percentile rank gating + BOS confirmation.
How to Read the Chart
ElementMeaningColored zones (rectangles)Liquidity pools labeled: source × touches, health%REJ 72.4 / ABS 85.1Reversal type + score out of 100 on sweepSFP | PR 7.2BullByte-style trigger with percentile rankTeal lineImpulse AVWAP (resets on every N-bar extreme)Aqua lineDaily AVWAP (resets every day)Dark green backgroundArmed Long — system is ready, waiting for BOS upDark red backgroundArmed Short — system is ready, waiting for BOS downSFP / SFP-LSwing Failure Pattern (Pivot / Level)Green/Red boxRisk Zone: SL + TP1 + TP2
Reversal Types
TypeWhat HappenedSignal StrengthRecommended SizingABS (Absorption)Large limit order absorbed the stop flow. Huge volume, strong wick★★★★★Full sizeREJ (Rejection)Volume delta opposite to sweep direction★★★★☆Full sizeDIV (Divergence)High volume pushed into the zone, but close didn’t hold★★★☆☆Half sizeEXH (Exhaustion)Sweep on thin volume, weak rejection★★☆☆☆Skip or 1/4 size
Pine Script® 인디케이터
Global Macro Bias IndicatorGlobal Macro Bias — Know the Environment Before You Trade
Most traders lose not because their setup was wrong — but because they traded against the macro environment without knowing it.
This indicator reads the macro backdrop for you. Every bar. Automatically.
It watches three things the big money watches:
— Whether the bond market is signaling growth or fear
— Whether the dollar is expanding or draining global liquidity
— Whether the market is in appetite or protection mode
Then it gives you one clear read:
🟢 RISK-ON — the environment favors longs and risk assets
🔴 RISK-OFF — the environment favors caution and safety
⚪ NEUTRAL — signals are mixed, better to wait
No numbers to crunch. No settings to change. You open the chart and you know.
How to use it:
— Before you take any trade, glance at the bias
— If you're looking to buy and it says RISK-OFF , that's your warning
— If it says RISK-ON STRONG and your setup aligns — that's confluence
— NEUTRAL means the macro isn't giving a clear edge, reduce size or wait
Works on any chart, any asset. Stocks, forex, crypto, commodities — macro affects everything.
If this helped you see the bigger picture, like and follow. More macro tools coming.
Pine Script® 인디케이터
Volume Dry-Up Reversal Planner [AGPro Series]Volume Dry-Up Reversal Planner
🧠 Core Idea
Is the market losing participation before a reversal attempt?
📌 Overview / What it does
Volume Dry-Up Reversal Planner detects low-participation pockets where relative volume contracts and candle range compresses.
The script maps a dry-up pocket, tracks whether price attempts to reverse out of that pocket, and displays reversal rails, failure shelves, follow-through references, event labels, and a compact AG Pro dashboard.
It does not predict reversals. It helps organize participation, compression, reaction quality, failure risk, and current action state around a potential dry-up reversal context.
🎯 Purpose & Design Philosophy
Many reversal tools focus on dramatic exhaustion candles or high-volume climaxes.
This script was built for a quieter but important condition: participation drying up before the next reaction.
It helps traders evaluate whether the market is simply inactive, compressing before movement, or beginning a structured reversal attempt from a low-participation pocket.
⚡ Why This Script Is Different
Most volume indicators highlight high-volume events.
This script does NOT chase volume climax or generic reversal signals.
Instead, it focuses on volume dry-up, range compression, reversal rails, failure shelves, follow-through context, and a 0-100 readiness score.
⚙️ Methodology
1. Participation Detection
The script compares current volume against recent average volume to identify low-participation candles.
2. Compression Mapping
Current candle range is compared with recent average range. A dry-up pocket requires both lower participation and controlled range compression.
3. Reversal Evaluation
After a dry-up pocket appears, the script watches whether price breaks beyond the pocket with enough quality to form a reversal attempt.
4. Visual Output
The chart receives a dry-up pocket, reversal rail, failure shelf, follow-through rail, right-side tags, event labels, optional bar coloring, and a dashboard panel.
🗺️ How to Read the Chart
The dry-up pocket marks the area where participation and range compressed.
The reversal rail shows the level price must clear to begin a reversal attempt.
The failure shelf marks where the active reversal context fails.
The follow-through rail marks the first reaction reference after a reversal attempt.
Labels highlight dry-up pockets, bullish reversal attempts, bearish reversal attempts, follow-through, and invalidation.
Colors represent context:
• Teal → bullish reversal attempt
• Pink → bearish reversal attempt or invalidation
• Gold → follow-through or waiting context
• Indigo → dry-up pocket / monitoring context
The panel summarizes:
• Dry-Up state
• Reversal Score
• Participation
• Failure Risk
• Action
🚦 Signals & States
• Dry-Up Pocket → relative volume and range both contracted
• Bull Reversal → price broke above the dry-up pocket
• Bear Reversal → price broke below the dry-up pocket
• Follow-Through → price reached the first reaction rail
• Invalidated → price crossed the failure shelf after a reversal attempt
• READY → reversal context has enough score quality to monitor
• MONITOR → reversal attempt is active but not fully ready
• WAIT → no strong active context exists
• EXPIRED → the dry-up pocket is too old to remain active
🔔 Alerts Logic
Alerts can trigger when a dry-up pocket appears, when a bullish or bearish reversal attempt begins, when the context reaches READY state, when follow-through appears, or when invalidation occurs.
Alerts are attention markers only. They are not trade instructions.
🧩 Confluence Logic
The context becomes stronger when relative volume contraction, range compression, close response, rejection quality, and volatility fit align.
For example, a low-volume compression pocket followed by a strong close outside the pocket can create a more structured reversal context than a random low-volume candle.
📊 When to Use
• Potential reversal areas after participation fades
• Pullback zones where volume dries up
• Ranging markets before directional reaction
• Trend pauses where continuation or reversal depends on participation
• Liquid crypto, indices, forex, and equities with readable volume behavior
⚠️ When NOT to Use
• Very low-liquidity symbols
• Markets with unreliable volume data
• News spikes and unstable spread conditions
• Extremely noisy candles without structure
• Situations where low volume simply means no meaningful market participation
🎛️ Key Inputs
• Relative Volume Length → controls the volume baseline
• Dry-Up Volume Threshold → controls how strict low-participation detection is
• Range Compression Length → controls the range baseline
• Maximum Range Ratio → controls how compressed the candle must be
• Dry-Up Pocket Window → controls how the pocket is mapped
• Reversal Buffer ATR → controls how far price must clear the pocket
• Failure Shelf ATR → controls where the reversal context fails
• Follow-Through ATR → controls the first reaction reference
• Visual settings → control pockets, rails, labels, tags, panel, and bar colors
🖥️ Interface & Visual Design
The interface is designed to make participation shifts visible without turning the chart into a noisy signal board.
The dry-up pocket defines context, the reversal rail defines the first reaction threshold, the failure shelf defines risk, and the panel summarizes the current state.
The goal is a premium, readable visual map for traders who care about participation and reaction quality.
🧪 Practical Usage Workflow
1. Check whether a dry-up pocket is active
2. Read the panel score and action state
3. Watch the reversal rail
4. Compare follow-through with failure risk
5. Confirm the context with broader market structure and timeframe alignment
🔍 Interpretation Guidelines
A dry-up pocket means participation and range compressed. It does not mean a reversal must happen.
A reversal attempt means price broke out of the pocket with enough reaction to monitor.
A READY state means the rule-based score has enough quality for attention.
Failure risk helps keep the reversal context grounded instead of treating every low-volume area as important.
🚫 What This Script Is NOT
This script is not a prediction engine.
It is not a guaranteed reversal system.
It is not a high-volume climax detector.
It is not an automated trading tool.
It does not provide financial advice.
It does not guarantee reversal, continuation, profit, or a specific target.
⚠️ Limitations & Transparency
Volume behavior differs across markets, exchanges, sessions, and timeframes.
Some dry-up pockets may lead to no meaningful reaction.
Some reversals may begin without a clean dry-up pattern.
The score is a rule-based context score, not a certainty model.
🧠 Market Context Notes
Volume dry-up can represent hesitation, absorption, exhaustion, or simple inactivity.
The important question is not whether volume is low by itself, but whether price reacts cleanly after participation contracts.
Use the pocket as context, not confirmation by itself.
🧾 Use Case Examples
When price pulls back with shrinking volume and compressed candles, the script can map a dry-up pocket.
If price later breaks above that pocket, the script marks a bullish reversal attempt and tracks follow-through.
If price breaks below the failure shelf after a reversal attempt, the script marks invalidation.
🧱 System Philosophy
This script follows the AGPro Series approach: turn a specific market condition into a structured decision-support map.
The focus is not prediction. The focus is participation, compression, reaction quality, failure awareness, and visual clarity.
🔐 Non-Promise Statement
No script can remove uncertainty from markets.
This tool does not promise accuracy, profitability, or future price movement.
Its purpose is to organize volume dry-up context so the user can interpret the chart more clearly.
📉 Risk Disclosure
Trading involves risk.
Market conditions can change quickly, and any analytical output can fail.
Users are responsible for their own decisions, risk management, and trade execution.
This script is for educational and analytical purposes only and does not provide financial advice.
📚 Educational Note
Low volume is not automatically bullish or bearish.
The best reads usually come when volume dry-up, range compression, reaction quality, and market structure all support the same context.
Pine Script® 인디케이터
